Advanced-control timer (TIM1) RM0453
820/1461 RM0453 Rev 1
25.4.23 TIM1 option register 1 (TIM1_OR1)
Address offset: 0x50
Reset value: 0x0000 0000
25.4.24 TIM1 capture/compare mode register 3
(TIM1_CCMR3)
Address offset: 0x54
Reset value: 0x0000 0000
The channels 5 and 6 can only be configured in output.
Output compare mode:
Bits 31:0 DMAB[31:0]: DMA register for burst accesses
A read or write operation to the DMAR register accesses the register located at the address
(TIMx_CR1 address) + (DBA + DMA index) x 4
where TIMx_CR1 address is the address of the control register 1, DBA is the DMA base
address configured in TIMx_DCR register, DMA index is automatically controlled by the DMA
transfer, and ranges from 0 to DBL (DBL configured in TIMx_DCR).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
TI1_
RMP
Res. Res.
TIM1_ETR_
ADC_RMP[1:0]
rw rw rw
Bits 31:5 Reserved, must be kept at reset value.
Bit 4 TI1_RMP: Input Capture 1 remap
0: TIM1 input capture 1 is connected to I/O
1: TIM1 input capture 1 is connected to COMP1 output
Bits 3:2 Reserved, must be kept at reset value.
Bits 1:0 TIM1_ETR_ADC_RMP[1:0]: TIM1_ETR_ADC remapping capability
00: TIM1_ETR is not connected to ADC AWDx (must be selected when the ETR comes from
the ETR input pin)
01: TIM1_ETR is connected to ADC AWD1
10: TIM1_ETR is connected to ADC AWD2
11: TIM1_ETR is connected to ADC AWD3
Note: ADC AWDx sources are ‘ORed’ with the TIM1_ETR input signals. When ADC AWDx is
used, it is necessary to make sure that the corresponding TIM1_ETR input pin is not
enabled in the alternate function controller.
