RM0453 Rev 1 187/1461
RM0453 Sub-GHz radio (SUBGHZ)
218
The correct values selected in the table below must be carefully tested to ensure a good
detection at sensitivity level and to limit the number of false detections.
Set_BufferBaseAddress() command
Set_BufferBaseAddress(TxBaseAddr, RxBaseAddr) sets the data buffer base
address for the packet handling in TX and RX.
(G)FSK Set_ModulationParams() command
Set_ModulationParams(Br, PulseShape, Bw, Fdev) is used to configure the
(G)FSK modulation parameters for the sub-GHz radio. Depending on the selected packet
Table 36. Recommended CAD configuration settings
SF CadDetPeak[7:0] CadDetMin[7:0]
5 0x18 0x10
6 0x19 0x10
7 0x20 0x10
8 0x21 0x10
9 0x22 0x10
10 0x23 0x10
11 0x24 0x10
12 0x25 0x10
012
Opcode TxBaseAddr[7:0] RxBaseAddr[7:0]
www
byte 0 bits 7:0 Opcode: 0x8F
byte 1 bits 7:0 TxBaseAddr[7:0]: Tx base address offset relative to the sub-GHz RAM base
address
byte 2 bits 7:0 RxBaseAddr[7:0]: Rx base address offset relative to the sub-GHz RAM base
address
