Power control (PWR) RM0453
274/1461 RM0453 Rev 1
6.6.22 PWR RSS command register (PWR_RSSCMDR)
This register is only reset by a power-on reset (not reset on NRST and exit from Standby).
Address offset: 0x098
Reset value: 0x0000 0000
Bits 31:16 Reserved, must be kept at reset value.
Bit 15 NSS: sub-GHz SPI NSS control
This bit is set and cleared by software and is used to control the sub-GHz SPI NSS level from
software.
0: sub-GHz SPI NSS signal at level low
1: sub-GHz SPI NSS signal is at level high
Bits 14:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. RSSCMD[7:0]
rw rw rw rw rw rw rw rw
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 RSSCMD[7:0]: RSS command
Define a command to be executed by the RSS.
