RM0453 Rev 1 1347/1461
RM0453 Debug support (DBG)
1448
38.5.2 AP transfer address register (AP_TAR)
Address offset: 0x04
Reset value: 0x0000 0000
38.5.3 AP data read/write register (AP_DRWR)
Address offset: 0x0C
Reset value: 0x0000 0000
Bits 5:4 ADDRINC[1:0]: auto-increment mode
Defines whether AP_TAR address is automatically incremented after a transaction.
0x0: No auto-increment
0x1: Address is incremented by the size in bytes of the transaction (SIZE field).
0x2: Packed transfers enabled
A 32-bit AP access gives rise to 1 x 32-bit, 2 x 16-bit or 4 x 8-bit bus transactions
corresponding to the programmed transaction size.
The data is packed or unpacked accordingly.
0x3: reserved
Bit 3 Reserved, must be kept at reset value.
Bits 2:0 SIZE[2:0]: size of next memory access transaction
0x0: Byte (8-bit)
0x1: Halfword (16-bit)
0x2: Word (32-bit)
0x3-0x7: reserved
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TA[31:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
TA[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 TA[31:0]: address of current transfer
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TD[31:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
TD[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 TD[31:0]: data of current transfer
