ST STM32WL5 Series User Manual

RM0453 Rev 1 217/1461
RM0453 Sub-GHz radio (SUBGHZ)
218
5.10.29 Sub-GHz radio register map
Table 42. SUBGHZ radio register map and reset values
Offset Register 76543210
0x06AC
SUBGHZ_GBSYNCR Res.
SBITSYNCEN
RXDINV
BITSYNCDIS
Res. Res. Res. Res.
Reset value 0 0 0
0x06AC
to
0x06B4
Reserved Reserved
0x06B8
SUBGHZ_GPKTCTL1AR Res. Res.
SYNCDETEN
CONTTX INFSQEQSEL[1:0]
INFSSQEQEN
WHITEINI[8]
Reset value 100001
0x06B9
SUBGHZ_GWHITEINIRL WHITEINI[7:0]
Reset value 00000000
0x06BC
SUBGHZ_GCRCINIRH CRCINI[15:8]
Reset value 00011101
0x06BD
SUBGHZ_GCRCINIRL CRCINI[7:0]
Reset value 00001111
0x06BE
SUBGHZ_GCRCPOLRH CRCPOL[15:8]
Reset value 00010000
0x06BF
SUBGHZ_GCRCPOLRL CRCPOL[7:0]
Reset value 00100001
0x06C0
SUBGHZ_GSYNCR7 SYNCWORD[63:56]
Reset value 10010111
0x06C1
SUBGHZ_GSYNCR6 SYNCWORD[55:48]
Reset value 00100011
0x06C2
SUBGHZ_GSYNCR5 SYNCWORD[47:40]
Reset value 01010010
0x06C3
SUBGHZ_GSYNCR4 SYNCWORD[39:32]
Reset value 00100101
0x06C4
SUBGHZ_GSYNCR3 SYNCWORD[31:24]
Reset value 01010110
0x06C5
SUBGHZ_GSYNCR2 SYNCWORD[23:16]
Reset value 01010011
0x06C6
SUBGHZ_GSYNCR1 SYNCWORD[15:8]
Reset value 01100101
0x06C7
SUBGHZ_GSYNCR0 SYNCWORD[7:0]
Reset value 01100100
0x06C8
to
0x073C
Reserved Reserved
0x0740
SUBGHZ_LSYNCRH SYNCWORD[15:8]
Reset value 00010100
0x0741
SUBGHZ_LSYNCRL SYNCWORD[7:0]
Reset value 00100100
