Extended interrupts and event controller (EXTI) RM0453
522/1461 RM0453 Rev 1
16.6.12 EXTI event mask register (EXTI_CnEMR2)
Address offset: Block 1: 0x094
Address offset: Block 2: 0x0D4
Reset value: 0x0000 0000
Bits 31:15 Reserved, must be kept at reset value.
Bit 14 IM46: wakeup with interrupt mask on event input 46
0: Wakeup with interrupt request from line 46 is masked.
1: Wakeup with interrupt request from line 46 is unmasked.
Bit 13 IM45: wakeup with interrupt mask on event input 45
Bit 12 IM44: wakeup with interrupt mask on event input 44
Bit 11 IM43: wakeup with interrupt mask on event input 43
Bit 10 IM42: wakeup with interrupt mask on event input 42
Bit 9 IM41: wakeup with interrupt mask on event input 41
Bit 8 IM40: wakeup with interrupt mask on event input 40
Bit 7 IM39: wakeup with interrupt mask on event input 39
Bit 6 IM38: wakeup with interrupt mask on event input 38
Bit 5 IM37: wakeup with interrupt mask on event input 37
Bit 4 IM36: wakeup with interrupt mask on event input 36
Bit 3 Reserved, must be kept at reset value.
Bit 2 IM34: wakeup with interrupt mask on event input 34
Bits 1:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. EM41 EM40 Res. Res. Res. Res. Res. Res. Res. Res.
rw rw
Bits 31:10 Reserved, must be kept at reset value.
Bit 9 EM41: wakeup with event generation mask on event input 41
0: Event request from line 41 is masked.
1: Event request from line 41 is unmasked.
Bit 8 EM40: wakeup with event generation mask on event input 40
Bits 7:0 Reserved, must be kept at reset value.
