RM0453 Rev 1 259/1461
RM0453 Power control (PWR)
276
6.6.4 PWR control register 4 (PWR_CR4)
This register is not reset when exiting Standby modes.
Access: additional APB cycles are needed to access this register versus those needed for a
standard APB access (three for a write and two for a read).
Address offset: 0x00C
Reset value: 0x0000 0000
Bit 2 EWUP3: wakeup pin WKUP3 for CPU1 enable
When this bit is set, the external wakeup pin WKUP3 is enabled and triggers an interrupt and
wakeup from Stop, Standby or Shutdown event when a rising or a falling edge occurs to
CPU1. The active edge is configured via the WP3 bit in the PWR control register 4
(PWR_CR4).
Bit 1 EWUP2: wakeup pin WKUP2 for CPU1 enable
When this bit is set, the external wakeup pin WKUP2 is enabled and triggers an interrupt and
wakeup from Stop, Standby or Shutdown event when a rising or a falling edge occurs to
CPU1. The active edge is configured via the WP2 bit in the PWR control register 4
(PWR_CR4).
Bit 0 EWUP1: wakeup pin WKUP1 for CPU1 enable
When this bit is set, the external wakeup pin WKUP1 is enabled and triggers an interrupt and
wakeup from Stop, Standby or Shutdown event when a rising or a falling edge occurs to
CPU1. The active edge is configured via the WP1 bit in the PWR control register 4
(PWR_CR4).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
C2BOOT
Res. Res. Res.
WRFBUSYP
Res. VBRS VBE Res. Res. Res. Res. Res. WP3 WP2 WP1
rw rw rw rw rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bit 15 C2BOOT: CPU2 boot after reset or wakeup from Stop or Standby mode
0: No CPU2 boot after reset or wakeup from Stop or Standby mode
1: CPU2 boot after reset and after wakeup from Stop or Standby mode, when there is a
CPU2 wakeup event
Bits 14:12 Reserved, must be kept at reset value.
Bit 11 WRFBUSYP: Wakeup radio busy polarity
This bit defines the polarity used for an event detection on radio busy signal.
0: Detection on high level (rising edge)
1: Detection on low level (falling edge)
Bit 10 Reserved, must be kept at reset value.
