Inter-integrated circuit (I2C) interface RM0453

1098/1461 RM0453 Rev 1

Caution: The PECBYTE bit has no effect when the RELOAD bit is set.

Figure 299. Transfer sequence flowchart for SMBus slave transmitter N bytes + PEC

Figure 300. Transfer bus diagrams for SMBus slave transmitter (SBC=1)

MS19867V2

Slave initialization

SMBus slave

transmission

Write I2C_TXDR.TXDATA

I2C_ISR.TXIS

=1?

Yes

I2C_ISR.ADDR =

Yes

Read ADDCODE and DIR in I2C_ISR

I2C_CR2.NBYTES = N + 1

PECBYTE=1

Set I2C_ICR.ADDRCF

SCL

stretched

MS19869V2

Example SMBus slave transmitter 2 bytes + PEC,

EV1: ADDR ISR: check ADDCODE, program NBYTES=3, set PECBYTE, set ADDRCF

EV2: TXIS ISR: wr data1

EV3: TXIS ISR: wr data2

ADDR

legend:

transmission

reception

SCL stretch

EV1 EV2

TXIS

EV3

NBYTES 3

S Address A Adata1

data2

PEC
