System configuration controller (SYSCFG) RM0453
436/1461 RM0453 Rev 1
11.2.8 SYSCFG configuration register 2 (SYSCFG_CFGR2)
Address offset: 0x01C
Reset value: 0x0000 0000
Bits 7:2 Reserved, must be kept at reset value.
Bit 1 SRAMBSY: SRAM1 or SRAM2 busy by erase operation
0: No SRAM1 or SRAM2 erase operation is ongoing.
1: SRAM1 or SRAM2 erase operation is ongoing.
See Section 2.4: SRAM erase for more information on SRAM erase conditions
Bit 0 SRAM2ER: SRAM2 erase
Setting this bit starts a hardware SRAM2 erase operation. This bit is automatically cleared at
the end of the SRAM2 erase operation.
Note: This bit is write-protected: setting this bit is possible only after the correct key sequence
is written in the SYSCFG_SKR register.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. SPF Res. Res. Res. Res. ECCL PVDL SPL CLL
rc_w1 rsrsrsrs
Bits 31:9 Reserved, must be kept at reset value.
Bit 8 SPF: SRAM2 parity error flag
This bit is set by hardware when an SRAM2 parity error is detected. It is cleared by software
by writing ‘1’.
0: No SRAM2 parity error detected
1: SRAM2 parity error detected
Bits 7:4 Reserved, must be kept at reset value.
Bit 3 ECCL: ECC lock
This bit is set by software and cleared only by a system reset. It can be used to enable and
lock the Flash ECC error connection to TIM1/16/17 break input.
0: ECC error disconnected from TIM1/16/17 break input.
1: ECC error connected to TIM1/16/17 break input.
