RM0453 Rev 1 1059/1461
RM0453 Inter-integrated circuit (I2C) interface
1126
The following additional features are also available depending on the product
implementation (see Section 34.3: I2C implementation):
• SMBus specification rev 3.0 compatibility:
– Hardware PEC (packet error checking) generation and verification with ACK
control
– Command and data acknowledge control
– Address resolution protocol (ARP) support
– Host and Device support
– SMBus alert
– Timeouts and idle condition detection
• PMBus rev 1.3 standard compatibility
• Independent clock: a choice of independent clock sources allowing the I2C
communication speed to be independent from the PCLK reprogramming
• Wakeup from Stop mode on address match.
34.3 I2C implementation
The devices incorporate up to three I²C-bus controllers, I2C1, I2C2, and I2C3, with full or
limited feature sets as shown in the following table.
34.4 I2C functional description
In addition to receiving and transmitting data, this interface converts it from serial to parallel
format and vice versa. The interrupts are enabled or disabled by software. The interface is
connected to the I
2
C bus by a data pin (SDA) and by a clock pin (SCL). It can be connected
with a standard (up to 100 kHz), Fast-mode (up to 400 kHz) or Fast-mode Plus (up to
1MHz) I
2
C bus.
Table 222. STM32WL5x I2C implementation
I2C features
(1)
1. X = supported.
I2C1
(2)
2. The register content is lost in Stop 2 mode.
I2C2
(2)
I2C3
7-bit addressing mode X X X
10-bit addressing mode X X X
Standard-mode (up to 100 kbit/s) X X X
Fast-mode (up to 400 kbit/s) X X X
Fast-mode Plus with 20mA output drive I/Os (up to 1 Mbit/s) X X X
Independent clock X X X
Wakeup from Stop mode X
(3)
3. Wakeup supported from Stop 0 and Stop 1 modes.
X
(3)
X
(4)
4. Wakeup supported from Stop 0, Stop 1 and Stop 2 modes.
SMBus/PMBus X X X
