RM0453 Rev 1 531/1461

RM0453 Cyclic redundancy check calculation unit (CRC)

531

17.4.6 CRC register map

Refer to Section 2.6 on page 70 for the register boundary addresses.

Table 99. CRC register map and reset values

Offset

name

0x00

CRC_DR DR[31:0]

Reset value

11111111111111111111111111111111

0x04

CRC_IDR IDR[31:0]

Reset value

00000000000000000000000000000000

0x08

CRC_CR

Res.

REV_OUT

REV_IN[1:0]

POLYSIZE[1:0]

Res.

RESET

Reset value 00000 0

0x10

CRC_INIT CRC_INIT[31:0]

Reset value 11111111111111111111111111111111

0x14

CRC_POL POL[31:0]

Reset value 00000100110000010001110110110111
