Debug support (DBG) RM0453
1354/1461 RM0453 Rev 1
38.6.5 DWT sleep count register (DWT_SLPCNTR)
Address offset: 0x010
Reset value: 0x0000 0000
38.6.6 DWT LSU count register (DWT_LSUCNTR)
Address offset: 0x014
Reset value: 0x0000 0000
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 EXCCNT[7:0]: exception overhead cycle counter
Counts the number of cycles spent in exception processing.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. SLEEPCNT[7:0]
rw rw rw rw rw rw rw rw
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 SLEEPCNT[7:0]: sleep cycle counter
Counts the number of cycles spent in sleep mode (WFI, WFE, sleep-on-exit).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. LSUCNT[7:0]
rw rw rw rw rw rw rw rw
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 LSUCNT[7:0]: load store counter
Counts additional cycles required to execute load and store instructions.
