Sub-GHz radio (SUBGHZ) RM0453
188/1461 RM0453 Rev 1
type in Set_PacketType() sent prior to this function, the parameters for generic packets
are interpreted as follows:
• Br and Fdev are used for the transmission and reception.
• Bw is used only for reception.
• PulseShape represents the Gaussian filter that can be used to filter the modulation
stream at the transmitter.
012345678
Opcode Br[23:0]
PulseShape[7:0]
Bw[7:0] Fdev[23:0]
wwwwwwwww
byte 0 bits 7:0 Opcode: 0x8B
bytes 3:1 bits 23:0 Br[23:0]: Bit rate
0x000000: reserved
0x000001 - 0xFFFFFF: Br = 32 x 32 MHz / bit rate
byte 4 bit 7:0 PulseShape[7:0]: Pulse shape
0x00: no filter applied
0x08:Gaussian BT 0.3
0x09: Gaussian BT 0.5
0x0A: Gaussian BT 0.7
0x0B: Gaussian BT 1.0
Others: no filter applied
