Device electronic signature RM0453

1452/1461 RM0453 Rev 1

Address offset: 0x04

Reset value: 0x0080 E115

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

STID[23:8]

rrrrrrrrrrrrrrrr

1514131211109876543210

STID[7:0] DEVID[7:0]

rrrrrrrrrrrrrrrr

Bits 31:8 STID[23:0]: company ID

0x0080E1 for STMicroelectronics

Bits 7:0 DEVID[7:0]: device ID

0x15
