RM0453 Rev 1 191/1461
RM0453 Sub-GHz radio (SUBGHZ)
218
Generic Set_PacketParams() command
Set_PacketParams(PbLength,PbDetLength,SynchWordLength,AddrComp,
PktType,PayloadLength,CrcType,Whitening) is used to configure the packet
handling for the sub-GHz radio. When the generic packet is selected with packet type in
Set_PacketType() sent prior to this function, the parameters are interpreted as below.
0123456789
Opcode PbLength[15:0]
PbDetLength[2:0]
SyncWordLength[6:0]
AddrComp[1:0]
PktType
PayloadLength[7:0]
CrcType[2:0]
Whitening
wwwwww
w
ww
w
byte 0 bits 7:0 Opcode: 0x8C.
bytes 2:1 bits 15:0 PbLength[15:0]: Preamble length in number of symbols
0x0000: reserved
0x0001 - 0xFFFF: 1 to 65535 symbols
byte 3 bits 7:3 Reserved, must be kept at reset value.
bits 2:0 PbDetLength[2:0]: Preamble detection length in number of bit symbols
0x0: preamble detection disabled
0x4: 8-bit preamble detection
0x5: 16-bit preamble detection
0x6: 24-bit preamble detection
0x7: 32-bit preamble detection
Others: reserved
byte 4 bit 7 Reserved, must be kept at reset value.
bits: 6:0 SyncWordLength[6:0]: Synchronization word length in number of bit symbols
0x00 - 0x40: 0 to 64-bit synchronization word (synchronization word data
defined in SUBGHZ_GSYNCR[0:7])
Others: reserved
byte 5 bits 7:2 Reserved, must be kept at reset value.
bits: 1:0 AddrComp[1:0]: Address comparison/filtering
0x0: address comparison/filtering disabled
0x1: address comparison/filtering on node address
0x2: address comparison/filtering on node and broadcast addresses
Others: reserved
byte 6 bits 7:1 Reserved, must be kept at reset value.
bit 0 PktType: Packet type definition
0: Fixed payload length and header field not added to packet
1: Variable payload length and header field added to packet
byte 7 bits 7:0 PayloadLength[7:0]: Payload length in number of bytes
0x00- 0xFF: 0 to 255 bytes
