4.3.4 Smart Card Reader Problem
FIGURE 4-28 Smart Card Reader Problem
Check the smart card
reader with OpenBoot
Diagnostics. See “Open-
Boot Diagnostics” on
page 8-5.
There is a problem with
the smart card reader.
Did
the smart card reader
pass the test?
Is the
operating system
running?
Is the ok prompt
displayed?
Press the Stop-A keys.
Check the smart card
reader with SunVTS. See
“SunVTS” on page 9-1.
Boot the operating sys-
tem. Type:
ok boot -r
Check the smart card
reader and replace if nec-
essary. See “Replacing
the Smart Card Reader”
on page 12-15.
N
Go to
N
Y
N
Y
N
Y
N
Type:
ls /dev/scmi2c0
Is the scmi2c0
file listed?
Y
N
Did
the smart card reader
pass the tests?
Problem with smart card
reader application. Con-
tact system administra-
tor.
Y
N
In normal operation, the smart card reader accepts Payflex
and Cyberflex smart cards for authentication. The LED in
the smart card reader provides status of the smart card.
Flashing amber means there are errors reading from or
writing to the card. See “Smart Card Reader” on
page C-32.
Checking a component means checking the electrical con-
nections and fit.
Check the smart card
reader and replace if nec-
essary. See “Replacing
the Smart Card Reader”
on page 12-15.
