Chapter 13 Replacing Chassis Components 13-3
TABLE 13-1 lists the power supply specifications.
13.1.2 Removing the Power Supply
1. Power off the system, open and position the chassis.
Refer to:
■ “Powering Off the Workstation” on page 10-4
■ “Removing the Access Panel” on page 10-12
■ “Positioning the Chassis” on page 10-16
2. Locate the power supply.
The power supply is fastened to the rear panel of the workstation chassis. See
FIGURE 13-1.
3. Release the cables out of the power supply cable routing clips.
See FIGURE 13-2.
TABLE 13-1 Power Supply Specifications
Specification Value
Input Voltage 100 - 240 VAC
Frequency 50 - 60 Hz
Current 8 amp, 4 amp
Wattage 420 W maximum
