Chapter 2 Product Description 2-5
FIGURE 2-2 Bezel Overview, Sun Blade 1500 Workstation
TABLE 2-2 Bezel Overview, Sun Blade 1500 Workstation
Callout in
FIGURE 2-2 Part Description Bezel Symbol
1 Smart card reader LED none
2 Smart card reader none
3 Optical drive none
4 Optical drive status LED none
5 Optical drive eject button
1
789
2
3
4
5
6
