Chapter 13 Replacing Chassis Components 13-41
FIGURE 13-43 Removing the Speaker Cable From the Bezel Cable Clip
4. Disconnect the speaker cable from the motherboard at connector SPK0.
See FIGURE 13-44.
SPK0
Bezel cable clip
