Sun Microsystems Blade 1500 - TABLE B-9 HD15 Video Output Port Pinouts; TABLE B-10 DVI-I Video Output Port Pinouts

B-8 Sun Blade 1500 Service, Diagnostics, and Troubleshooting Manual • December 2004
TABLE B-9 lists the pinouts of the HD-15 video output port.
TABLE B-10 lists the pinouts of the DVI-I video output port.
TABLE B-9 HD15 Video Output Port Pinouts
Pin Signal
1 Red analog video
2 Green analog video
3 Blue analog video
4 No Connect
5 Ground
6 Ground
7 Ground
8 Ground
9 +5V Supply
10 Ground
11 No Connect
12 DDC Bidirectional Data (SDA)
13 Horizontal/Composite Sync
14 Vertical Sync
15 DDC Data Clock (SCL)
TABLE B-10 DVI-I Video Output Port Pinouts
Pin Signal
1 TMDS Data2 -
2 TMDS Data2 +
3 TMDS Data2/4 Shield
4 TMDS Data4 - (no connect XVR-600 or XVR-1200)
5 TMDS Data4 + (no connect XVR-600 or XVR-1200)
6 DDC Clock (SCL)
7 DDC Data (SDA)
8 Analog Vertical Sync
9 TMDS Data1 -
10 TMDS Data1 +
