Chapter 14 Replacing Internal Cables 14-29
FIGURE 14-26 Connecting the Audio and USB Cables to the Motherboard
5. Guide the audio USB board cables through the I/O cable clip at the bottom of the
chassis and close the clip.
See FIGURE 14-27.
Connector J19 USB
Connector
J13 AUDIO
