Chapter 12 Replacing Storage Devices 12-15
11. Install the bezel, the access panel, power on the system, and verify the optical
drive installation.
Refer to:
■ “Installing the Bezel” on page 15-2
■ “Installing the Access Panel” on page 15-5
■ “Powering On the Workstation” on page 15-8
■ “Verifying an Installation” on page 15-11
Note – If you installed a CD-RW drive, remember to either boot or reboot the
system with the -r option, so that the Solaris operating system can reconfigure itself
for the new CD-RW drive.
Note – If so equipped, do not remove the plastic rivet from the headphone jack of
the optical drive. Instead, use the headphone jack at the bottom of the workstation
front panel.
12.3 Replacing the Smart Card Reader
This section describes removal and installation of the smart card reader. Topics
include:
■ “Identifying the Smart Card Reader” on page 12-15
■ “Removing the Smart Card Reader” on page 12-16
■ “Installing the Smart Card Reader” on page 12-20
Click this film icon to view an animated version of these instructions.
12.3.1 Identifying the Smart Card Reader
The workstation supports one smart card reader. The smart card reader is installed
on the smart card reader bracket. The bracket has drive rails that enable it to slide
into the removable media bay. See
FIGURE 12-13. The removable media bay is
accessible when the front bezel is removed. The smart card reader connector is
accessible when the access panel is removed.
