Chapter 10 Preparing to Replace Components 10-3
Caution – The boards and hard drives contain electronic components that are
extremely sensitive to static electricity. Ordinary amounts of static electricity from
clothing or the work environment can destroy components. Do not touch the
components along their connector edges.
Caution – Wear an antistatic wrist strap and use an antistatic mat when handling
components such as drive assemblies, boards, or cards. When servicing or removing
workstation components, attach an antistatic strap to your wrist and then to a metal
area on the chassis. Then disconnect the power cord from the workstation and the
wall receptacle. Following this caution equalizes all electrical potentials with the
workstation.
10.2 Required Tools
The Sun Blade 1500 workstation was designed to be serviced with the following
tools:
■ Number 2 Phillips screwdriver
■ Antistatic wrist strap
■ Antistatic mat
■ Container for screws
See FIGURE 10-1.
FIGURE 10-1 Required Tools
Antistatic mat
Antistatic wrist strap
Small container
Number 2 Phillips screwdriver
