Chapter 2 Product Description 2-7
Note – The combination card connectors for your Sun Blade 1500 workstation might
be reversed when compared with FIGURE 2-3. Their function is the same.
2.3 Replaceable Components
FIGURE 2-4 shows the replaceable components of the Sun Blade 1500 workstation.
TABLE 2-3 Rear Panel Overview, Sun Blade 1500 Workstation
Callout in
FIGURE 2-3 Part Description Rear Panel Symbol
A Power connector none
B USB v1.1 connector (2)
C Serial1 connector (DB-9)
D Parallel connector (DB-25)
E Serial2 connector (DB-9)
F Twisted-pair Ethernet (TPE)
G Audio connector, line-out
H Audio connector, line-in
I Graphics accelerator
J IEEE 1394/USB v2.x combination
card with 2 IEEE 1394a connectors
and 3 USB v2.0 ports
K PCI card connector (66 MHz): PCI
connector 4
L PCI card connectors (33 MHz): PCI
connector 0, PCI connector 1, PCI
connector 2, and PCI connector 3
1
2
PCI 4
66
PCI 3
PCI 2
PCI 1
PCI 0
