Chapter 15 Finishing Component Replacement 15-7
FIGURE 15-6 Closing the Access Panel
10. Tighten the access panel thumbscrews.
See FIGURE 15-7.
FIGURE 15-7 Tightening the Access Panel Thumbscrews
Note – Do not use a screwdriver to tighten the thumbscrews. Tighten the
thumbscrews only finger tight.
Access
panel
