Chapter 14 Replacing Internal Cables 14-23
■ The power switch assembly cable is secure in the metal clamp and bezel cable
clip.
11. Install the bezel, the access panel, power on the system, and verify the power
switch assembly installation.
Refer to:
■ “Installing the Bezel” on page 15-2
■ “Installing the Access Panel” on page 15-5
■ “Powering On the Workstation” on page 15-8
■ “Verifying an Installation” on page 15-11
14.6 Replacing the Audio USB Board Cables
This section describes removal and installation of the audio USB board interface
cables. Topics include:
■ “Identifying the Audio USB Board Cables” on page 14-23
■ “Removing the Audio USB Board Cables” on page 14-24
■ “Installing the Audio USB Board Cables” on page 14-27
14.6.1 Identifying the Audio USB Board Cables
The audio USB board has two separate cable sets, one for audio and one for USB.
The audio signals are carried by three shielded multi-conductor cables connecting to
the motherboard at J13 AUDIO. The USB interface cable is a 10-conductor ribbon
cable connecting at J19 USB.
FIGURE 14-21 shows the audio USB board cable
connections.
