Sun Microsystems Blade 1500 - Removing the Front Fan

Chapter 13 Replacing Chassis Components 13-9
FIGURE 13-8 Front Fan Location and Identification
Note – Though similar in appearance, the front and rear fan brackets are not
interchangeable.
TABLE 13-2 lists the front fan specifications.
13.2.2 Removing the Front Fan
1. Power off the system and open the chassis.
Refer to:
■ “Powering Off the Workstation” on page 10-4
■ “Removing the Access Panel” on page 10-12
TABLE 13-2 Front Fan Specifications
Specification Value (Maximum)
Voltage 12 VDC
Current 0.490 AMPS
Speed 3600 RPM
Flow Rate 66 CFM (1.86 m
3
/min)
Tabs (4)
Latch
Connector FAN0 SYS
