Sun Microsystems Blade 1500 - Functional Mode; Functional Mode Component Testing

9-6 Sun Blade 1500 Service, Diagnostics, and Troubleshooting Manual • December 2004
9.2.3 Functional Mode
Functional mode allows for multiple passes and thorough configuration of each
device test. Such configuration is beyond the scope of this manual. As such, only
simplified functional mode tests are described. For more information about SunVTS’
functional and exclusive mode testing, refer to the SunVTS documentation described
in
“SunVTS Software” on page 5-6.
For simplified functional mode tests, output is only displayed upon error.
Note – You cannot test system sensors in functional mode.
9.2.4 Functional Mode Component Testing
To test a specific component in functional mode, follow this procedure. Perform
steps 1 through 7, then use
TABLE 9-2 for step 6 and additional steps. If you want to
test more than one component, test one component at a time, then restart the
procedure from
Step 6 for the second and subsequent components.
CPU
6. Select Processor(s)
7. Click Reset.
8. Click Start.
Connection test starting....
Processor(s)
cpu-unit0
Status: Connected
sparcv9 processor operating at frequency 1500 MHz.
08/30/04 14:19:53 dt92-238 SunVTS5.1ps5build3: VTSID 4002
iutest(P0).INFO cpu-unit0: sparcv9 based processor running @
1500MHz Online
cpu-unit0
Status: "Connected
A sparcv9 processor operating at 1600 MHz.
08/30/04 14:19:54 dt92-238 SunVTS5.1ps5build3: VTSID 2001
l1dcachetest.INFO l1cache: "Connected : CPU (cpu-id = 0 )
Level 1 cache : size 64 Kbytes line 32 bytes associativity 4"
Connection test complete
USB
6. Select USB
7. Click Reset.
8. Click Start.
Connection test starting....
Connection test complete
TABLE 9-1 Subsequent Steps to Test Components in Connection Mode (Continued)
Component Steps to Take Successful Test Results
