Chapter 12 Replacing Storage Devices 12-17
FIGURE 12-14 Removing the Smart Card Reader Interface Cable From the Reader Cable
Clip
4. Disconnect the interface cable from the motherboard at SCR0.
See FIGURE 12-15.
SCR0
Reader cable clip
