Replacing Chassis Components
This chapter describes the remove and install procedures for the Sun Blade 1500
workstation chassis components.
The procedures described in this chapter are written for workstation service
providers and system administrators.
This chapter contains the following topics:
■ “Replacing the Power Supply” on page 13-2
■ “Replacing the Front Fan” on page 13-8
■ “Replacing the Rear Fan” on page 13-15
■ “Replacing the DIMM Cooling Duct” on page 13-22
■ “Replacing the Audio USB Board” on page 13-30
■ “Replacing the Speaker” on page 13-39
■ “Replacing the PCI Card Support” on page 13-45
■ “Replacing the Chassis Cross Brace” on page 13-49
■ “Replacing the Drive Rails” on page 13-59
Caution – To prevent equipment damage, review the safety requirements, safety
symbols, and safety precautions in “Preparing to Replace Components” on page 10-1
before you perform any replacement procedure. Additional cautions, warnings, and
instructions are provided in the Sun Blade 1500 Safety and Compliance Guide, 817-5130.
The document is available from:
http://www.sun.com/documentation.
Caution – Many of the procedures in this chapter are performed with the
workstation chassis laying on its side. If you perform any of the procedures in this
chapter with the chassis in its upright position, use care that you do not tip over the
chassis.
