Sun Microsystems Blade 1500 - FIGURE 14-25 Connecting Cables to the Audio USB Board

14-28 Sun Blade 1500 Service, Diagnostics, and Troubleshooting Manual • December 2004
3. Connect the cables to both the audio and the USB connectors on the audio USB
board.
See FIGURE 14-25.
FIGURE 14-25 Connecting Cables to the Audio USB Board
4. Connect the audio and USB cables to the connectors on the motherboard at J19
USB and J13 AUDIO.
See FIGURE 14-22.
Audio cable
USB cable
