Sun Microsystems Blade 1500 - TABLE B-22 Power Supply Connector PS2 Pinouts

Appendix B Signal Descriptions B-17
B.2.6.3 PS2 Information
Connector PS2 supplies primary power for the Sun Blade 1500 motherboard.
TABLE B-22 lists the pinout for PS2.
10 +3.3 V
11 +3.3 V
12 Ground
TABLE B-22 Power Supply Connector PS2 Pinouts
Pin Signal
1 +3.3 V
2 +3.3 V
3 Ground
4 +5 V
5 Ground
6 +5 V
7 Ground
8 P.G.S
9 +5 VSB
10 +12 V
11 +3.3 V
12 -12 V
13 Ground
14 PS-On
15 Ground
16 Ground
17 Ground
18 None
19 +5 V
20 +5 V
TABLE B-21 Power Supply Connector PS1 Pinouts (Continued)
Pin Signal
