Sun Microsystems Blade 1500 - Removing the Rear Fan; TABLE 13-3 Rear Fan Specifications; FIGURE 13-14 Rear Fan Location and Identification

13-16 Sun Blade 1500 Service, Diagnostics, and Troubleshooting Manual • December 2004
FIGURE 13-14 Rear Fan Location and Identification
TABLE 13-3 lists the rear fan specifications.
13.3.2 Removing the Rear Fan
1. Power off the system and open the chassis.
Refer to:
■ “Powering Off the Workstation” on page 10-4
■ “Removing the Access Panel” on page 10-12
TABLE 13-3 Rear Fan Specifications
Specification Value (Maximum)
Voltage 12 VDC
Current 0.490 AMPS
Speed 3600 RPM
Flow Rate 66 CFM (1.86 m
3
/min)
Catch
Gap
Gap
Tabs (4)
Latch
Connector
FAN1 SYS
