Sun Microsystems Blade 1500 - TABLE B-11 BNC NTSC;PAL Video Output Port Pinouts; TABLE B-12 Mini-DIN7 Stereoscopic Imager Interface Connector Pinouts

Appendix B Signal Descriptions B-9
TABLE B-11 lists the pinouts of the BNC NTSC/PAL video output port.
TABLE B-12 lists the pinouts of the Mini-DIN7 stereoscopic imager interface connector
11 TMDS Data1/3 Shield
12 TMDS Data3 - (no connect XVR-600 or XVR-1200)
13 TMDS Data3 + (no connect XVR-600 or XVR-1200)
14 +5V Power
15 Gnd (+5, Analog V/H Sync)
16 Hot Plug Detect
17 TMDS Data0 -
18 TMDS Data0 +
19 TMDS Data0/5 Shield
20 TMDS Data5 - (no connect XVR-600 or XVR-1200)
21 TMDS Data5 + (no connect XVR-600 or XVR-1200)
22 TMDS Clock Shield
23 TMDS Clock+
24 TMDS Clock-
C1 Analog Red Video
C2 Analog Green Video
C3 Analog Blue Video
C4 Analog Horizontal Sync
C5 Analog Gnd (R, G, and B return)
TABLE B-11 BNC NTSC/PAL Video Output Port Pinouts
Pin Signal
center Signal
shield Ground
TABLE B-12 Mini-DIN7 Stereoscopic Imager Interface Connector Pinouts
Pin Signal
1 Signal ground
TABLE B-10 DVI-I Video Output Port Pinouts (Continued)
Pin Signal
