C-24 Sun Blade 1500 Service, Diagnostics, and Troubleshooting Manual • December 2004
C.5.2 Sun XVR-100
The Sun XVR-100 graphics accelerator provides the following features and benefits:
■ 2D 24-bit graphics
■ Flexible 8- and 24-bit color application support
■ 24-bit color, high resolution for multihead displays in supported systems
■ HD15 and DVI monitor connectors for a wide range of Sun and third party
monitors
■ 3D support through the software
Screen Resolutions and Video Formats
TABLE C-6 lists the monitor screen resolutions and video formats supported by the
Sun XVR-100 graphics accelerator.
800 × 600 75 VESA 4:3 4
640 x 480 60 Hz VESA 4:3 8
1. Samples Per Pixel (SPP).
TABLE C-6 Sun XVR-100 Graphics Accelerator Monitor Screen Resolutions
Display
Resolution
Vertical Refresh Rate Sync Standard Aspect Ratio Format
1920 x 1200 60 Hz (DVI-D port) See Note. Sun 16:10
1920 x 1200 60, 70, 75 Hz (HD-15 port) Sun 16:10
1920 x 1080 60, 72 Hz Sun 16:9
1600 x 1280 76 Hz Sun 5:4
1600 x 1200 65, 70, 75, 85 Hz VESA 4:3
1600 x 1000 66, 76 Hz Sun 16:10
1440 x 900 76 Hz Sun 16:10
1280 x 1024 60, 75, 85 Hz VESA 5:4
1280 x 1024 67, 76 Hz Sun 5:4
1280 x 800 76 Hz Sun 16:10
TABLE C-5 Sun XVR-600 Graphics Accelerator Monitor Screen Resolutions (Continued)
Display Resolution Vertical Refresh Rate Sync Standard
Aspect Ratio
Format
SPP
1
Single
Screen
