14-2 Sun Blade 1500 Service, Diagnostics, and Troubleshooting Manual • December 2004
Caution – When servicing or removing workstation components, attach an
antistatic strap to your wrist and then to a metal area on the chassis. Then disconnect
the power cord from the workstation and the wall receptacle. Following this caution
equalizes all electrical potentials with the workstation.
The Sun Blade 1500 workstation replaceable cables come as a set that includes:
■ Smart card reader cable
■ Removable media interface cable
■ Hard drive interface cable
■ IDE power cable
■ Power switch assembly
■ Audio USB board cables (two)
FIGURE 14-1 shows cable connectors and slots for the Sun Blade 1500 motherboard.
