B-14 Sun Blade 1500 Service, Diagnostics, and Troubleshooting Manual • December 2004
5 D6
6 D9
7 D5
8 D10
9 D4
10 D11
11 D3
12 D12
13 D2
14 D13
15 D1
16 D14
17 D0
18 D15
19 Ground
20 none
21 DRQ
22 Ground
23 IOW#
24 Ground
25 IOR#
26 Ground
27 IURDY
28 Ground
29 DACK#
30 Ground
31 IRQ
32 none
33 A1
34 CBLID
TABLE B-18 IDE Interface Connectors IDE PRI and IDE SEC Pinouts (Continued)
Pin Signal
