V1.2.2

CMS32L051 User Manual |Chapter 12 Universal Serial Communication Unit

www.mcu.com.cn 373 / 703

(3) Processing flow (single send and receive mode)

Figure 12-65 Timing diagram of slave transmit and receive (single transmit and receive mode)

(type 1: DAPmn=0, CKPmn=0).

SCLKp pin

SDOp pin

INTSSPIp

shift register mn

TSFmn

SDRmn

SEmn

STmn

SSmn

SDIp pin

transmit data1 transmit data 2

transmit data 3

data reception1

data reception2

data reception3

data reception1 data reception2 data reception3

Receiving&shift operation

transmit data1 transmit data 2

transmit data 3

data transmission and reception data transmission and reception data transmission and reception

Read

Write

Read

Write

Read

Remark m: Unit number (m=0, 1) n: Channel number (n=0~3) p: SSPI number (p=00, 01, 10, 11, 20, 21)

mn=00~03, 10~11.
