V1.2.2

CMS32L051 User Manual |Chapter 12 Universal Serial Communication Unit

www.mcu.com.cn 406 / 703

(3) Processing flow (single send and receive mode)

Figure 12-91 Timing diagram of slave transmit and receive (single-send and receive mode)

(Type 1: DAPmn=0, CKPmn=0).

SCLKp pin

SDOp pin

INTSSPIp

shift register mn

TSFmn

SDRmn

SEmn

STmn

SSmn

SSp pin

SDIp pin

data reception1

data reception2 data reception3

transmit data1

transmit data 2

transmit data 3

Read

Write

Read

Write

data reception1 data reception2

data reception3

Receiving&shift operation

transmit data1

transmit data 2

transmit data 3

data transmission and reception data transmission and reception data transmission and reception

Remark m: Unit number (m=0) n: Channel number (n=0) p: SSPI number (p=00)
