CMS32L051 User Manual |Chapter 14 Serial interface IICA

www.mcu.com.cn 546 / 703

(b) A condition in which arbitration fails during the sending of the extension code

ST AD6~AD0 R/W ACK D7~D0 ACK D7~D0 ACK SP

1 2

1:IICSn=01000110B

2:IICSn=00000001B

set LRELn bit to '1' via software

Remark must generate

only generate while SPIEn bit is '1'

(i)

When WTIMn = 0

ST AD6~AD0 R/W ACK D7~D0 ACK D7~D0 ACK SP

1 2 3

1:IICSn=10001110B

2:IICSn=01000000B

3:IICSn=00000001B

Remark must generate

only generate while SPIEn bit is '1'

any

Note n=0
