SecureStack B3 Configuration Guide 19-1

IPv6 Management

ThischapterdescribestheswitchmodesetofcommandsusedtomanageIPv6.

Purpose

ToenableordisabletheIPv6managementfunction,toconfigureanddisplaytheIPv6host

addressandIPv6gatewayfortheswitch,andtodisplayIPv6statusinformation.

Commands

show ipv6 status

UsethiscommandtodisplaythestatusoftheIPv6managementfunction.

Syntax

show ipv6 status

Parameters

None.

For information about... Refer to page...

show ipv6 status 19-1

set ipv6 19-2

set ipv6 address 19-2

show ipv6 address 19-3

clear ipv6 address 19-4

set ipv6 gateway 19-5

clear ipv6 gateway 19-6

show ipv6 neighbors 19-6

show ipv6 netstat 19-7

ping ipv6 19-8

traceroute ipv6 19-8
