RM0390 USB on-the-go full-speed/high-speed (OTG_FS/OTG_HS)
1264
0xB30
OTG_
DOEPTSIZ1
Res.
RXDPID/
STUPCNT
PKTCNT XFRSIZ
Reset value 0000000000000000000000000000000
0xB34
OTG_
DOEPDMA1
DMAADDR
Reset value 00000000000000000000000000000000
.
.
.
.
.
.
.
.
.
.
.
.
0xBA0
OTG_
DOEPCTL5
EPENA
EPDIS
SODDFRM
SD0PID/SEVNFRM
SNAK
CNAK
Res. Res. Res. Res.
STALL
SNPM
EPTYP
NAKSTS
EONUM/DPID
USBAEP
Res. Res. Res. Res.
MPSIZ
Reset value 000000 0000000 00000000000
0xBA8
OTG_
DOEPINT5
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
STPKTRX
NYET
NAK
BERR
Res. Res. Res.
OUTPKTERR
Res.
B2BSTUP
STSPHSRX
OTEPDIS
STUP
AHBERR
EPDISD
XFRC
Reset value 0000 0 0000000
0xBB0
OTG_
DOEPTSIZ5
Res.
RXDPID/
STUPCNT
PKTCNT XFRSIZ
Reset value 0000000000000000000000000000000
.
.
.
.
.
.
.
.
.
.
.
.
0xC00
OTG_
DOEPCTL8
EPENA
EPDIS
SODDFRM
SD0PID/SEVNFRM
SNAK
CNAK
Res. Res. Res. Res.
STALL
SNPM
EPTYP
NAKSTS
EONUM/DPID
USBAEP
Res. Res. Res. Res.
MPSIZ
Reset value 000000 0000000 00000000000
0xC08
OTG_
DOEPINT8
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
STPKTRX
NYET
NAK
BERR
Res. Res. Res.
OUTPKTERR
Res.
B2BSTUP
STSPHSRX
OTEPDIS
STUP
AHBERR
EPDISD
XFRC
Reset value 0000 0 0000000
0xC10
OTG_
DOEPTSIZ8
Res.
RXDPID/
STUPCNT
PKTCNT XFRSIZ
Reset value 0000000000000000000000000000000
Table 231. OTG_FS/OTG_HS register map and reset values (continued)
Offset
Register
name
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
