RM0453 Rev 1 1373/1461
RM0453 Debug support (DBG)
1448
CTI channel out status register (CTI_CHOUTSTSR)
Address offset: 0x13C
Reset value: 0x0000 0000
CTI channel gate register (CTI_GATER)
Address offset: 0x140
Reset value: 0x0000 000F
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. CHOUTSTATUS[3:0]
rrrr
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 CHOUTSTATUS[3:0]: channel output status
There is one bit of the register for each channel output. When a bit is set to 1, it indicates that
the corresponding channel output is active. When it is set to 0, the corresponding channel
output is inactive.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. GATEEN[3:0]
rw rw rw rw
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 GATEEN[3:0]: channel output enable
For each channel, defines whether an event on that channel can propagate over the CTM to
other CTIs.
0000: Channels events do not propagate.
XXX1: Channel 0 events propagate.
XX1X: Channel 1 events propagate.
X1XX: Channel 2 events propagate.
1XXX: Channel 3 events propagate.
