TASK 47-11-01-400-801
5. Air Separation Module Assembly Installation
(Figure 402)
A. General
(1) This is an alternate task to install the air separation module (ASM). The high flow valve [14],
muscle air duct [9], and NEADS duct [27] are installed on the ASM before installation on the
airplane.
B. References
Reference Title
47-00-00-790-801 Leak Check of the Nitrogen Generation System (P/B 601)
47-00-00-800-801 Ground Operation of the Nitrogen Generation System (P/B 201)
SWPM 20-20-00 ELECTRICAL BONDING PROCESSES
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-1550 Bonding Meters - Approved, Intrinsically Safe (Approved for use in
Class I, Divisions I & II hazardous (classified) locations. Outside
these hazardous locations, COM-614 can be used in lieu of
COM-1550).
737-600, -700, -800
Part #: 620LK Supplier: 1CRL2
Part #: M1 Supplier: 3AD17
Part #: T477W (C15292) Supplier: 01014
Opt Part #: M1B Supplier: 3AD17
D. Consumable Materials
Reference Description Specification
B00130 Alcohol - Isopropyl TT-I-735
C00852 Compound - Antiseize, Molybdenum
Disulfide-Petrolatum
MIL-PRF-83483
C50285 Primer - Epoxy MIL-PRF-23377 Type 1
Class C2
D50063 Grease - Perfluoropolyether, fuel and oxygen
resistant - Krytox 240AC
MIL-PRF- 27617 Type III
G00034 Cotton Wiper - Process Cleaning Absorbent
Wiper (Cheesecloth, Gauze)
BMS15-5 Class A
G50706 Tape - Jehier KB-23, 3-Inch (76.2 mm) Wide BMS5-172 TYPE I
G51019 Tape - ECC-A fiberglass tape, 0.005 Inches
(0.127 mm) Thick, 1/2 Inch (12.7 mm) Wide
MIL-Y-1140 Class C
Form 5
G51020 Tape - ECC-A fiberglass tape, 0.007 Inches
(0.1778 mm) Thick, 1/2 Inch (12.7 mm) Wide
MIL-Y-1140 Class C
Form 5
G51066 Tape - ECC-B fiberglass tape, 0.005 Inches
(0.127 mm) Thick, 1/2 Inch (12.7 mm) Wide
MIL-Y-1140 Class C
Form 5
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-11-01
Page 437
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
