AC EXTERNAL POWER - ADJUSTMENT/TEST
1. General
A. This procedure has this task:
(1) AC External Power Operational Test.
TASK 24-41-00-700-801
2. AC External Power Operational Test
(Figure 501, Figure 502)
A. References
Reference Title
20-40-11-910-801 Static Grounding (P/B 201)
24-22-00-860-812 Remove Electrical Power (P/B 201)
B. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
D. Prepare for the operational test
SUBTASK 24-41-00-860-001
(1) Do this task: Remove Electrical Power, TASK 24-22-00-860-812.
SUBTASK 24-41-00-860-002
(2) Make sure the BAT switch on the P5-13 panel is set to the ON position.
SUBTASK 24-41-00-860-003
(3) Make sure the STANDBY POWER switch on the P5-5 panel is set to the AUTO position.
SUBTASK 24-41-00-860-004
(4) Make sure the BUS TRANS switch on the P5-4 panel is set to the AUTO position.
SUBTASK 24-41-00-860-005
(5) Make sure that these circuit breakers are closed:
F/O Electrical System Panel, P6-4
Row Col Number Name
E 13 C01328 ELECTRICAL GND SERV CONT
F 13 C01290 GENERATOR BUS PWR CONT UNIT
SUBTASK 24-41-00-010-001
(6) To get access to the main equipment center, open this access panel:
Number Name/Location
117A Electronic Equipment Access Door
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-41-00
Page 501
D633A101-ILF Jun 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
