SUBTASK 47-32-05-020-002
(5) Do these steps to remove the bonding jumper [2]:
(a) Remove the sealant from the ram air valve [1] at the bonding tab location.
(b) Remove the bolt [11], washer [12], bonding jumper [2] and nut [14].
1) Keep the bolt [11], washer [12], bonding jumper [2] and nut [14] for the installation.
SUBTASK 47-32-05-020-001
(6) Do these steps to disconnect the ram air valve [1]:
(a) Disconnect the muscle air line [4] from the ram air valve [1].
(b) Disconnect the coupling [8] on the flexible hose [7] side.
1) Keep the coupling [8] for the installation.
2) Remove and discard the two O-rings [9]
(c) Loosen the hose clamp [6].
(d) Disconnect the flexible hose [7] from the exhaust duct [5].
1) Keep the flexible hose [7] and the hose clamp [6] for the installation.
(e) Hold the ram air valve [1] in its position.
(f) Disconnect the coupling [13] from the heat exchanger.
1) Keep the coupling [13] for installation.
(g) Remove the ram air valve [1].
(h) Remove the seal [15].
SUBTASK 47-32-05-490-001
(7) Install protective covers on the heat exchanger and the exhaust duct [5].
END OF TASK
