SUBTASK 53-05-02-410-059
(3) Close these access panels on the Left side:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191FL Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air
Inlet
Close these access panels on the Right side:
Number Name/Location
191AR Forward Wing To Body Fairing Panel - Upper
191FR Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air
Inlet
END OF TASK
TASK 53-05-02-250-845
65. INTERNAL - SPECIAL DETAILED: WING TO BODY UPPER DRAG ANGLE
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
125 Air Conditioning Distribution Bay - Left
126 Air Conditioning Distribution Bay - Right
131 Center Section Wing Box, Body Station 540.00 to Body Station 663.75 - Left
132 Center Section Wing Box, Body Station 540.00 to Body Station 663.75 - Right
191 Lower Wing-To-Body Fairing - Forward of Wing Box
B. Access Panels
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191AR Forward Wing To Body Fairing Panel - Upper
191FL Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air Inlet
191FR Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air Inlet
C. Inspection
SUBTASK 53-05-02-010-064
(1) Open these access panels on the Left side:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191FL Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air
Inlet
Open these access panels on the Right side:
Number Name/Location
191AR Forward Wing To Body Fairing Panel - Upper
191FR Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air
Inlet
NOTE: Removal of wing to body fairings and duct located aft of STA 536 is required.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 238
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
