TASK 47-31-01-400-801
3. Nitrogen Generation System Controller Installation
(Figure 401)
A. General
(1) This nitrogen generation system controller is referred to at the controller [1] in this task.
B. References
Reference Title
25-52-17-400-801 Forward Cargo Compartment Aft Bulkhead Liner - Installation
(P/B 401)
47-00-00-800-801 Ground Operation of the Nitrogen Generation System (P/B 201)
SWPM 20-20-10 Standard Wiring Practices Manual
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-1550 Bonding Meters - Approved, Intrinsically Safe (Approved for use in
Class I, Divisions I & II hazardous (classified) locations. Outside
these hazardous locations, COM-614 can be used in lieu of
COM-1550).
737-600, -700, -800
Part #: 620LK Supplier: 1CRL2
Part #: M1 Supplier: 3AD17
Part #: T477W (C15292) Supplier: 01014
Opt Part #: M1B Supplier: 3AD17
D. Consumable Materials
Reference Description Specification
A50006 Compound - Sealing, Thread-Locking,
Anaerobic, Single-Component (100-200
In-Lbs)
MIL-S-46163 Type II
Grade M
E. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Controller 47-31-01-01-030 ILF 402, 451, 452, 503,
504, 508-510, 514, 516,
523-528, 541, 568, 569,
573-577, 581, 583, 585,
588-590, 592-599,
601-603, 606, 607,
610-615, 620, 625-627,
691-699, 832-835, 838,
854, 856, 971, 980-999
F. Location Zones
Zone Area
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
125 Air Conditioning Distribution Bay - Left
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-01
Page 405
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
