Boeing 737-600 - Subtask 30-71-06-010-001; Subtask 30-71-06-010-002; Subtask 30-71-06-020-001; Subtask 30-71-06-020-002

(Continued)
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 412, 501, 507, 512, 513,
516, 518, 531, 532, 556, 557, 560-562, 567-569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607,
610-615, 620, 625-627, 671, 672, 691-699, 803-813, 821, 822, 831-838, 841, 842, 851, 852, 854-858,
861-863, 871-874, 947, 948, 968-973, 980-999
E 18 C01473 HOSE HEATERS
ILF 401, 402, 405, 406, 409, 410, 416, 424, 425, 427-429, 451, 452, 491-500, 502-504, 508-510, 514,
515, 519, 520, 523-528, 530, 533, 535-537, 541, 542, 552-555, 559, 563, 564, 571-577, 686, 703,
707-710
F 16 C01473 HOSE HEATERS
ILF ALL
SUBTASK 30-71-06-010-001
(3) Open this access panel:
Number Name/Location
822 Aft Cargo Door
SUBTASK 30-71-06-010-002
(4) Get access to the applicable heated potable water hose.
(a) Use the schematic (SSM 30-71-11) to determine the location of the heated water hoses.
(b) Use (Figure 401) to identify access requirements.
(c) Do the necessary tasks to access the heated water hose.
1) Remove the cargo compartment floor panel. To do this, do this task: Cargo Floor
Panel Removal, TASK 25-52-10-000-801.
2) Remove the aft bulkhead liner. To do this, do this task: Aft Cargo Compartment Aft
Bulkhead Liner - Removal, TASK 25-52-19-000-801.
3) Remove cargo compartment sidewall lining. To do this, do this task: Cargo
Compartment Sidewall Lining - Removal, TASK 25-52-06-000-801.
4) Remove the carpet. To do this, do this task: Carpet Removal,
TASK 25-27-15-000-801.
5) Remove the floor covering. To do this, do this task: Entry and Service Area Floor
Covering - Removal, TASK 25-27-21-000-801.
F. Heated Potable Water Hose Removal
SUBTASK 30-71-06-020-001
(1) Disconnect the electrical connectors (WDM 30-71-12) from the heated hose.
SUBTASK 30-71-06-020-002
(2) Disconnect the fittings on the heated potable water hose.
(a) Use a bucket to catch water which may be in the hose.
(b) For details to remove flexible hoses refer to: (TASK 20-10-52-000-801).
END OF TASK
