TASK 24-34-31-400-803-002
3. Static Inverter RCCB Installation
(Figure 401, Figure 402)
A. General
(1) The Static Inverter RCCB, C1341, is located on the J9 Battery Shield in the Main Equipment
Center.
B. References
Reference Title
24-22-00-860-813 Supply External Power (P/B 201)
24-31-21-710-801 Main Battery Charger Operational Test (P/B 501)
24-31-31-710-801 Auxiliary Battery Charger Operational Test (P/B 501)
FIM 24-31 TASK 801 P5-13 ELEC Light Message BITE Procedure
SWPM 20-83-00 Standard Wiring Practices Manual
C. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Static inverter RCCB 24-34-31-01-015 ILF 101, 151, 156-199,
301, 304, 308, 310, 314,
315, 317-319, 323,
331-399, 401, 402, 405,
406, 409, 410, 412, 416,
424, 425, 427-429, 451,
452, 491, 492, 501-504,
507-510, 512-516,
518-520, 523-528,
530-533, 535-537, 541,
542, 552-557, 559,
571-577, 703, 803-813,
821, 822, 831, 832, 836,
837
24-34-31-02-015 ILF 560, 561, 567-569,
581, 583, 585, 589, 590,
601-603, 606, 607,
610-615, 620, 671, 672,
691-699, 835, 838, 841,
842, 851, 852, 857, 858,
947, 948, 968-973,
980-999
24-34-31-03-015 ILF 493-500, 563, 564,
597-599, 625-627
D. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-34-31
Config 2
Page 408
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-561, 563,
564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599, 601-603, 606, 607,
610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
